240W LED Linear High Bay Light YR-LH421

Yaorong LED Linear High Bay Light Advantages

—————

1.Constant current drive: Yaorong Technology LED high bay lights use high-performance drive, which is equivalent to a light bulb with a strong heart. The voltage is stable, there is no visible flicker, the brightness is uniform, and the constant current makes the IC consume less energy, less self-heating, and prolong the service life.

2.The material is environmentally friendly: the interior of the LED high bay light does not contain mercury and other heavy metals. When damaged or destroyed, it will not cause danger or pollution to human health and the environment. It can also be recycled, in line with the characteristics of green and environmental protection.

3.No radiation: LED industrial and mining lamps do not produce ultraviolet rays, and the light is relatively mild. Unlike traditional lamps that produce strong ultraviolet rays, the surroundings of LED industrial and mining light sources are cleaner and hygienic.

4.Anti-ultraviolet design: The LED high bay lamp of Yaorong Technology is made of PC material, which has high strength, fatigue resistance, dimensional stability, small creep, and almost no change under high temperature conditions. Anti-UV, no discoloration and no aging in indoor and outdoor use.

5.Low energy consumption: Yaorong Technology LED high bay lights have high electro-optical conversion efficiency. Compared with traditional light source lighting, they can save energy by more than 50%, greatly reduce power consumption, and achieve energy-saving purposes.

6.Wide range of applications: Yaorong Technology LED high bay lights have a variety of beam angles, lenses or reflectors to choose from to meet the needs of various occasions. It is suitable for illuminating various lighting areas such as factories, gymnasiums, warehouses, squares, transportation places, airports, subways, commercial districts, overpasses, billboards, buildings, etc.

Yaorong LED Linear High Bay Light Certification

—————

Yaorong LED Linear High Bay Light Parameters

—————

LED Linear High Bay Light
Model	CRI	Luminous Flux	Power
YR-LH420-W100	≥70	10000LM	100W
YR-LH420-W160	≥70	16000LM	160W
YR-LH420-W240	≥70	24000LM	240W
YR-LH420-W320	≥70	32000LM	320W
YR-LH421-W150	≥70	15000LM	150W
CCT	30K/40K/50K/60K/70K
Warranty	5 years
Temperature	-40°~85°
Power Efficiency	≥0.9
Protection level	IP54
Beam angle	120°
Shell Color	Black/White/Customized Color
Certification	FC/UL/DLC/CE/ROHS/SAA

Yaorong LED Linear High Bay Light Distribution Curve

—————

Yaorong LED Linear High Bay Light Distribution Curve

Yaorong NB-IOT Single Controller Parameters

—————

NB-IOT Single controller
Name	YR-NB73-12 single controller	Temperature	-40°~85°
Power	DC12V	Sensitivity	-135dBm
Communication	NB-IOT wireless network communication interface Fully comply with NB-IOT narrowband communication standard	Frequency	LTE NB-IOT B3/B5/B8/B26
Switch output	1 way, contact 12V/16A	Transmit power	23dBm
Dimming output	1 way, 0-10V/PWM	Protection level	IP65
Elec Parameter	Voltage, current, power, factor, electric energy	Antenna type	Built-in
Model	YR-NB73-220、YR-NB73-12 YR-M5310-220、YR-M5310-12	Dimensions	848497mm
Advantages	1. Grouping, time control, light control, induction, latitude and longitude switch lights; 2. Dimmable from 0 to 100%; 3. With system monitoring function and positioning alarm function;

LED Linear High Bay Light Size Atlas

—————

LED Linear High Bay Light Installation Method Atlas

—————

Precautions For The Installation Of LED Linear High Bay Light

—————

Please cut off the power before installation and make sure that the installation part can bear the weight of the lamp.
In order to prevent the lamp from falling off, please make sure that the installation is correct.
Please do not use it in a place with corrosive gas.
Please do not cover any material on the lamp.
For safety, please connect the ground wire securely.
This LED lamp has a five-year warranty from the date of purchase.
However, failures caused by disassembly, modification, or improper construction of this product are not within the scope of this warranty.

Five-year warranty

—————

Yaorong Technology is committed to providing customers with cost-effective LED lighting products. And provide high-quality after-sales service ahead of peers.Yaorong Technology provides a 5-year warranty. However, unauthorized disassembly or destruction of Yaorong Technology LED lighting products will not be eligible for warranty service.If you need after-sales service support, please contact our after-sales staff during the warranty period. Yaorong Technology after-sales engineers communicate with you about after-sales matters.

Yaorong LED Linear High Bay Light Case

—————
